GUIDE TN-650 Thermal Binoculars with Integrated Laser Rangefinder
SKU: Guide-TN-650
Professional-Grade Thermal Surveillance. Engineered for Tactical Superiority.
The GUIDE TN-650 represents the pinnacle of thermal imaging technology—designed for military professionals, law enforcement agencies, search and rescue teams, and specialized hunters requiring absolute reliability, clarity, and precision under any condition. With a high-resolution 640×480 VOx sensor, long-range laser rangefinder, advanced onboard tech, and rugged environmental resilience, the TN-650 is a full-spectrum thermal solution built for real-world operations.
Optical & Sensor Performance
Sensor Type: Uncooled VOx Infrared Detector, 8 to 14μm
Thermal Resolution: 640 × 480 @ 12μm
Thermal Sensitivity (NETD): ≤30mK
Frame Rate: 50Hz
Objective Lens: 50mm, F1.2
Field of View (Angular): 8.78° × 6.59°
Field of View (Linear @ 100m): 15 × 12 meters
Magnification: 2.8x to 22.4x (digital zoom)
Detection Range: 2600 meters / 2800 yards
Focus: Manual
Display & Viewing
Display Type: 0.39" AMOLED, 1024 × 768 resolution
Color Palettes: Black Hot, White Hot, Adjustable Red Hot, Iron Red, Blue Hot, Green Hot
Eyepiece Specs:
Eye Relief: 16mm
Diopter Adjustment: -6 to +6
Interpupillary Distance: Adjustable from 60mm to 70mm
Max Zoom: 13.8x
Integrated Technologies
Laser Rangefinder: 1500 meters / 1630 yards
Wireless Connectivity: 2.4GHz Wi-Fi, Bluetooth
Onboard Sensors: GPS, Digital Compass, Gyroscope
Recording Capability: Photo and video capture
Internal Storage: 16GB
Data Ports: USB-C, Micro HDMI
Power & Battery System
Battery Type: Dual replaceable 18650 rechargeable batteries
Operating Time: Up to 5.5 hours continuous use
Power Management: Efficient, field-replaceable battery design for extended operational uptime
Environmental & Durability Specifications
Operating Temperature Range: -30°C to +50°C / -22°F to +122°F
Ingress Protection Rating: IP66 – dust-tight and protected against high-pressure water jets
Weight: 880g / 31.04 oz
Dimensions: 162 × 146 × 70 mm / 6.38 × 5.75 × 2.76 inches
Standard Package Includes:
GUIDE TN-650 Device
50mm Lens Cover
Two Detachable Eye Masks
Rugged Carry Bag
Neck Strap
5V2A Charger (US, UK, AU, and EU Adapters)
Two Replaceable 18650 Batteries
Battery Charger
USB-A to USB-C Cable
Micro HDMI to HDMI Cable
Quick Start Guide
Warranty Card
Optional Accessories: Bluetooth Remote Control, Extended Mounting Bracket
Operational Advantage
The GUIDE TN-650 is more than a thermal optic—it is a fully integrated reconnaissance system. Designed for critical applications where certainty matters, it delivers superior detection, target acquisition, and environmental awareness across the full range of terrain and climate conditions. From tactical overwatch to search and rescue, the TN-650 gives you a decisive operational edge.
Limited availability. This is a mission-grade optic built for professionals who require uncompromising thermal performance.
